Sperry MK 37 VT Gyrocompass set for sale:
We have these Sperry Marine MK 37 VT Gyrocompass sets for sale. The master compass (MFR Part No. 03956-1891974-11) comes with a Digital Display / Control Unit an Electronics Control Panel and two analog repeaters. Several units of Sperry Marine gyro compass are readily available in stock. Gyro sphere for this Gyrocompass MK 37 VT is also available separately. Please contact us if you require MK 37VT master compass, related accessories, or gyro sphere for this model. Sample photos and further details on Sperry MK 37 VT are given below.
Send us your inquiry for Sperry MK-37 VT
Sperry Marine MK-37 VT – State of the art gyrocompass system:
The Sperry Marine MK37 VT Digital Gyrocompass is built according to the highest industry standards for commercial gyro-compass systems for marine use. The MK37 delivers excellent performance with its user friendly and well designed compact system that brings to the user numerous options for utmost optimization of the system for distinct application needs.
In use aboard hundreds of vessels worldwide, the MK37 system is considered to be one of the most reliable and accurate low-cost commercial gyro compass set-up in the world today.
Sperry MK 37 VT Gyrocompass – Highlights of features:
- Superior Performance based upon Sperry’s Industry Standard MK37 Master Compass
- Compact three-unit design – reduces cable requirements
- Proven reliable master compass
- User-friendly display/control panel includes an additional heading repeater
- Simultaneous output of heading data in analog and serial formats
- Automatic transfer feature with dual system configurations
- Innovative course and rudder angle recorder option available
Sperry MK 37 VT Gyrocompass – Technical Specifications:
- Linear Mean Settle Point Error: +/- 0.19 degrees Secant Latitude
- Scorsby Error (+/- 25 deg. roll, +/- 15 deg. Pitch): 0.90 degrees Secant Latitude
- Master Compass Angular Freedom: Better than +/- 45 degrees in roll and pitch
- Speed Correction: Manual or Automatic with Speed Log input
- Latitude Correction: Manual or Automatic with GPS input
- Sperry MK37 VT Gyrocompass – Settle Time: Less than 5 hours unaided
- Temperature Range: Complies with ISO 8728
- Serial Data Inputs: One serial RS232 and one RS422 input.
- Speed – The MK37 VT can accept NMEA 0183 “VHW” and /or “VBW” messages for speed input.
- Latitude – Critical Latitude data is derived from position messages. The MK37 VT system monitors input for “GCA” and/or “GLL” sentences
- Speed Input, Contact Closure: 200 Pulses per nautical mile contact closure input. The system considers the speed within the range of 0 to 70 knots as valid.
- Serial Heading & Status Outputs: One RS-422 and two RS-232 serial outputs to distribute digital heading. All data is in NMEA 0183 format. The RS-422 line is capable of driving up to 10 loads from a single output. The RS-232 outputs can drive a single load.
- Step Channel Output: Eight Step Data outputs; 24 VDC, 6 steps per degree
- Rate of Turn Output: One analog rate of turn output; -50mV per degree/minute (+/- 4.5 volts full scale = +/- 90 degrees/minute) output will drive up to 3 indicators
- Power Failure Alarm Output: Power Fail relay contacts (Form Contacts) – (Rated at 1 amp @ 30 VDC and/or 300 mA @ 115 VAC)
- Compass Failure Alarm/Contacts: Compass Failure alarm relay contacts (Form Contacts) – (Rated at 1 amp @ 30 VDC and/or 300 mA @ 115 VAC)
- Power Requirements of Sperry MK-37 VT gyrocompass:
- Input Voltages: 115/230 VAC, +/- 10%, 47-64 Hz
- Mains: +24 VDC @ 8 A
- Emergency: +24 VDC @ 8 A
We can ship this gyrocompass system Sperry MK-37 VT worldwide. Contact us now for the deals available on this gyrocompass.
